•Thetransducersshouldbeinstalledawayfromanyprotrusionssuchasothertransducers,steps,
ribs,strak
es,orrowsofrivets.
1
S tep
2
Rib
3R owofrivets
4
S trake
•T ransducersshouldbeinstalledinalocationwherenoloadwillbeappliedtothetransducers
during,launching,lifting,traileringandstorageoftheboat.
•Transducersmustbeinstalledinthecorrectorientation,withtheanti-rotationboltclosestto
thesternofthevessel.Additionally,adirectionarrowpointingtothebowisembossedonthe
anti-rotationboltcap.
•Wheninstallingsplit-pairtransducers:
–thecorrecttransducer(portorstarboard)mustbeinstalledinthematching(portorstarboard)
sideofthehull;eachtransducerinasplitpairhasalabelontheattachedcable,andmarkings
andlabelsonthetransducerbodytohelpyouidentifythetransducer:
ItemColorDescription
1R edPort-sidesplit-pairtransducercable
2GreenS tarboard-sidesplit-pairtransducercable
Installation23
