Accessories
MI3 Rev. G Nov/2015 73
Figure 60: Maximum Ambient Temperature is dependent on Air Flow and Hose Length
Note: “Hose Length“ is the length of the hose exposed to high ambient temperature (not the overall
length of the hose).
Hose Length
60 l / min (2.1 cubic feet per minute)
Air Flow:
50 l / min (1.8 cfm)
40 l / min (1.4 cfm)
