40 ST6000 Plus Autopilot Control Unit Owner,s Handbook
Setting Description
DISPL MNT Displacement
SEMI DIS Semi-displacement
PLANING Planing
STERN DRV Sterndrive
Default: Displacement
Calibration lock
Calibration lock controls whether User Setup and Intermediate Setup
are available, and is intended for charter boat users.
Setting Description
ON Setup ON
OFF Setup OFF
Default: OFF
Rudder gain
This must be set while under way, as described in Chapter 7, Post
Installation Procedures.
Range: 1 to 9
Default: 5 (Displacement)
5 (Semi-displacement)
4 (Planing)
3 (Sterndrive)
Rate level
Rate Level applies rudder to reduce rate or changes of course. Rate
level will, if the rate at which the vessel is turning is too fast, counter this
turn with opposite rudder.
