Chapter 5: Customising the System
47
AutoRelease
AutoRelease provides emergency manual override, should it be
necessary, to avoid an obstacle at the last moment. This option only
applies to cable operated sterndrive actuators for all other systems this
option should be set to off.
Range: Off
On
Defaults: 0 for Displacement, Semi-displacement &
Planing
1 for Sterndrives
Response
This is the power-on response setting. The response level can be
changed during normal operation (see section 3.3) or via the Response
Data Page, if this is set for display (see section 2.6).
Range: Level 1 (Auto Seastate)
Level 2 (Auto sea state inhibit)
Level 3 (Auto sea state inhibit counter rudder)
Default: Level 1
Recording calibration settings
Having fine-tuned the calibration settings during initial sea trials,
record them for future reference, in the table on the following page.
