52 ST6000 Plus Autopilot Control Unit Owner,s Handbook
4. Screw the fixing studs (2) into the display head.
5. Pass the cables (SeaTalk, NMEA) through the bulkhead.
6. Fit the cables to the appropriate terminals (see relevant subsection
for connection details of each item)
7. Fit the display head to the bulkhead.
8. Assemble the thumb nuts (3) onto the fixing studs (2).
9. Tighten the thumb nuts by hand until the display head is secure.
Under no circumstances must wrenches be used to tighten the
thumb nuts.
Connections to the SeaTalk bus
SeaTalk cables
The ST6000 Plus is supplied with a 9m SeaTalk cable as standard.
The following table lists other cables available from your dealer:
Part No: Type Length
D187 Flat to a male round connector 0.15 m (6 in) long
D188 Flat to a female round connector 0.3 m (12 in) long
D284 Flat moulded plugs at both ends 1 m (3 ft 3 in) long
D285 Flat moulded plugs at both ends 3 m (9 ft 9 in) long
D286 Flat moulded plugs at both ends 6 m (19 ft 6 in) long
D287 Flat moulded plugs at both ends 9 m (29 ft 3 in) long
Cable types
The following illustration shows the different types of SeaTalk cables
available.
