Raytheon ST6000 Plus - NMEA Cable Connectors; NMEA Data Transmission

54 ST6000 Plus Autopilot Control Unit Owner,s Handbook
Red
(Data In +ve)
Blue
(Data In -ve)
D3442-1
Navigator
with NMEA output
NMEA cable connectors
 NMEA connections are made using spade connectors.
 When fitting the spade connectors, make sure the connector fits
securely over the blade and not between the connector and its plastic
insulating boot  incorrect fitting will give intermittent contact
which will lead to faulty autopilot operation.
NMEA data transmission
If you wish to transmit NMEA information to other equipment a
SeaTalk Interface should be installed.
