Technical data
Wavelength
1064nm, 15nm, 450nm
Fiber interface
QBH (standard configuration), QD
Clear aperture
28mm
Collimation length
50mm, 100mm, 125mm, 150mm
Focus length
100mm, 150mm, 200mm, 250mm, 300mm
Cover glass specifications
Φ27.9mm*4.1mm (focus)
CCD connection module
Standard C/CS interface
Model description
Take BW2103FA4B as an example:
BW210 Series BW210
3 Power rating of the welding head: 3KW
F Wavelength
A Fiber interface: QBH
4 Optical configuration: 100:150
B with CCD; without lens temperature monitoring
