2 Installation and Operation
2.1 Preparations
As tip assembly of the product (Series BW210) is selected by customers, before installation, please ensure the package
includes these modules of tip assembly: coaxial nozzle, air knife, and side blow.
The laser head and tip assembly shall be locked firmly with M3x10 hex cap screws, as shown below:
