RBH Access Technologies UNC100 Hardware Manual

UNC100 Hardware Manual V1.4 RBH Access Technologies Inc.
Page 13 of 36
DIP Switch Settings
The UNC100 DIP switch controls the device’s address and serial port baud rate.
To Clear Panel memory – All DIP switches must be off and the unit powered off and on.
DIP Switch
DIP Switch
Function
1 - 4
Controller Address
5
Ethernet Secure Mode
1
6,7
Controller Baud Rate
8
Not used
Controller Addressing
Use DIP switches 1, 2, 3, and 4 to select the controller address. The address is binary coded and the
switch settings for all fifteen possible addresses are given below.
Controller Addressing
Switch 1
Switch 2
Switch 3
Switch 4
Address
On
Off
Off
Off
1 (Master)
Off
On
Off
Off
2 (Slave)
On
On
Off
Off
3 (Slave)
Off
Off
On
Off
4 (Slave)
On
Off
On
Off
5 (Slave)
Off
On
On
Off
6 (Slave)
On
On
On
Off
7 (Slave)
Off
Off
Off
On
8 (Slave)
On
Off
Off
On
9 (Slave)
Off
On
Off
On
10 (Slave)
On
On
Off
On
11 (Slave)
Off
Off
On
On
12 (Slave)
On
Off
On
On
13 (Slave)
Off
On
On
On
14 (Slave)
On
On
On
On
15 (Slave)
1
DIP switch 5 up will enables Ethernet Secure Mode. This will prevent access to the panel’s programming through
the Ethernet.

RBH Access Technologies UNC100 Specifications

General

Model	UNC100
Category	IP Access Controllers
Operating Voltage	12VDC
Current Consumption	500mA
Reader Ports	2
Certifications	CE, FCC
Weight	200g
Communication	Ethernet
Communication Interface	10/100 Mbps Ethernet
Outputs	4
Output Relay	2
Reader Input	Wiegand
