I n t r o d u c t i o n
The RBH-UNC100 series is a welcome addition to the new
generation of powerful and reliable Axiom hardware. The two
door native TCP/IP controllers come equipped with onboard
battery backup chargers and accommodate up to 16 individual
IOC-16 input/output controllers or 254-SafeSuite keypads. The
units are expandable to 8 doors, using 3 additional RC-2 or
NIRC/NURC controllers.
The UNC-100 also features a 32-bit processor with encryption
and expanded memory.
The UNC100-132 models come equipped with IEEE 802.3at
compliant PoE capability, further increasing this UNC series’
award-winning efficiency.
POE Features are:
 IEEE 802.3at Compliant
 30 Watt power rating
 Built-in battery backup with charger
 Operates with non-compliant PoE+PSEs
 Available auxiliary power output
UNC-100 unit fits into existing enclosures and if ordered with metal
protective shell can be mounted directly on back boards or inside of 3rd party
cabinets.
UNC-100 uses AES-256 bit encryption for secure communication over Ethernet. This communication
can be either between the host computer & master panel or amongst the master & slave panels. Both panel
& the host computer needs to be provided with a Customer Key and need to enable AES option both in
Axiom and UNC-100.
