6. Remove the stopper from the air tubeset and connect it to the pump.
The correct connection is completed with a "click". Connect the bed
headrest elevation detector to the pump.
7. Connect the lift detection sensor (only in model MD090F-1301BTRF)
8. Make sure that the power cord is disconnected from the power source and
connect it to the pump, cover it with the red cap built-in the pump to prevent
accidental disconnection of the cable and press down toward the pump.
9. Plug in to the power source.
10. Before turning the pump on, make sure the CPR valve is in the CLOSE position and the Easy Turn
Technology valves are in the OPEN positions.
①Easy Turn Technology valve (yellow) ② CPR quick deflation valve (red)
CAUTION: The pump may only be connected to a dedicated mattress recommended by the
manufacturer. Do not use it for purposes other than those specified in this manual.
