Control module STM 21 RED 5
B6_Control_SYS20_EN_V1.3.doc Art. Nr. 102-020401135 26 / 36
Multifunctional key Function, after pulses have been given
1 pulse
Releases an opening movement (AKI)
2 pulses
Calibrating ELS
3 pulses
Calibrating door parameters
4 pulses
Entering programming level
5 pulses
RED
 Redundancy test, if system connected to mains voltage
DUO
 Battery emergency reaction, as long as system discon-
nected from mains
 Battery test in case of mains connection
8 pulses
Loads default values of door type selected
9 pulses
Back to factory settings (afterwards emergency stop must be
actuated within 10 seconds)
14 pulses
Hardware reset is performed after approx. 12 seconds
Connector designation Connections
J1
Terminals 25 – 28  for BDE-D
J2
Terminals 1 – 12:
Functions according to wiring diagram 102-020110534
J3
Terminals 13 – 17 (only used with RED applications):
Functions according to wiring diagram 102-020110534
J4
Battery 1 (used for DUO and RED applications)
J5
Battery 2 (only used for RED applications)
J6
Locking
J7
Motor brake
J8
ATE motor 1
J9
ATE motor 2
J10
CAN bus / CAN sensors
J11
Extra printed circuit board ELS (ZLP-ELS)
J12
Extra printed circuit board AKI (ZLP-AKI)
J13
CAN bus plug for FPC-servicing
J14
Reserved for future modules
J15
Encoder motor 1
J16
Encoder motor 2
J17
Reserved for future modules
J18
Reserved for future modules
