Control module STM 20 2
B6_Control_SYS20_EN_V1.3.doc Art. Nr. 102-020401135 9 / 36
9 pulses
Back to factory settings
(afterwards an emergency stop or a reset must be actuated
within 10 seconds) The function emergency-stop with reset
can only be actuated if the INPUT/OUTPUT parameter
Emergency-Stop with Reset is active!!
14 pulses
Hardware-Reset will be done after approx 12 sec.
Connector designation Connections
J1
Mains plug
J2
Terminals 25 - 28 for BDE-D
J3
Terminals 1 - 12:
Functions according to wiring diagram 102-020109934
J4
Locking device
J5
Battery
J6
Motor brake
J7
ATE motor
J8
CAN bus
J9
CAN bus plug for FPC-servicing
J10
Encoder motor
J11
Extra printed circuit board ELS (ZLP ELS)
J12-14
Reserved for future modules
