red lion PXU11A20 User Manual

-14-
Drawing No. LP0932 Released 2018-01-12


PARAMETER DESCRIPTION RANGE/UNITS
FACTORY
SETTING
Px
Active Setpoint Value Input Range Dependent
0
C1
Current Monitor Input (read only)
OP1
Control Output 1 0 to 100%
0.0
OP2
Control Output 2 0 to 100%
0.0
PrP
Setpoint Ramp Rate 0 to 999 display units/minute
0
PId
PID Group
1, 2, 3, 4, 5, 6, Auo
1
r-
Controller Status
rN or OP (Profile Mode: Pnd, PA, PAdv)
rN
P
Profile Status (read only)
r-i
Profile Segment Time remaining (read only)
ProF
Setpoint Profile
0-9, A-F
0
P9
Starting Profile Segment
0-9, A-F
0
OPOF
Output Power Offset 0.0 to 100.0%
50.0
ProP
Proportional Band 0 to 9999 % display units
0
In
Integral Time 0 to 9999 seconds.
120
dr
Derivative Time 0 to 9999 seconds per repeat
30
dIn
Integration Default Default Integration Value 0.0 to 100.0%
0.0
AL-1
Alarm 1 Value Input Range Dependent
100
AL-2
Alarm 2 Value Input Range Dependent
200
AL-3
Alarm 3 Value Input Range Dependent
300
ALr
Alarm reset
1-2 ( B Resets AL1; J Resets AL2)
ALr
Alarm Reset
3 ( J Resets AL3)
PL
Setpoint Select
P-1 to P-6
P-1
N
Auto-Tune Start
NO or Y
NO
CrL
Control Mode
OnOF or P1d
P1d
P
Setpoint Mode
P, ProF, RMO
P
rnF
Control Mode Transfer
Auo or r
Auo
dv
Setpoint Deviation Display Units
P1
Setpoint 1
dIP, PArP, Id, LOC
P2
Setpoint 2
dIP, PArP, Id, LOC
Cod
Access Code
-125 to 125
0
