-5-
Released 2018-01-12 Drawing No. LP0932

DIN SIZE
MAIN CONTROL
OUTPUT 1
SECONDARY
CONTROL
OUTPUT 2
USER
INPUT(S)
REMOTE
SETPOINT INPUT
CT
INPUT
ANALOG
OUTPUT
(RETRANS)
RS 485
PART NUMBERS
100 to 240 VAC 24 VDC
1/16 DIN
Relay PXU10020 PXU100B0
Relay Relay 2 Yes PXU11A20 PXU11AB0
Relay Relay 1 Yes Yes PXU11B20 PXU11BB0
Relay Relay 1 Yes Yes PXU11C20 PXU11CB0
Relay Relay 1 Yes Yes PXU11D20 PXU11DB0
Logic/SSR PXU20020 PXU200B0
Logic/SSR Relay 2 Yes PXU21A20 PXU21AB0
Logic/SSR Relay 1 Yes Yes PXU21B20 PXU21BB0
Logic/SSR Relay 1 Yes Yes PXU21C20 PXU21CB0
Logic/SSR Relay 1 Yes Yes PXU21D20 PXU21DB0
4-20 mA PXU30020 PXU300B0
4-20 mA Relay 2 Yes PXU31A20 PXU31AB0
4-20 mA Relay 1 Yes Yes PXU31B20 PXU31BB0
4-20 mA Relay 1 Yes Yes PXU31C20 PXU31CB0
4-20 mA Relay 1 Yes Yes PXU31D20 PXU31DB0
0-10 VDC PXU40020 PXU400B0
0-10 VDC Relay 2 Yes PXU41A20 PXU41AB0
0-10 VDC Relay 1 Yes Yes PXU41B20 PXU41BB0
0-10 VDC Relay 1 Yes Yes PXU41C20 PXU41CB0
0-10 VDC Relay 1 Yes Yes PXU41D20 PXU41DB0
1/8 DIN
Relay PXU10030 PXU100C0
Relay Relay 2 Yes PXU11A30 PXU11AC0
Relay Relay 1 Yes Yes PXU11B30 PXU11BC0
Relay Relay 1 Yes Yes PXU11C30 PXU11CC0
Relay Relay 1 Yes Yes PXU11D30 PXU11DC0
Logic/SSR PXU20030 PXU200C0
Logic/SSR Relay 2 Yes PXU21A30 PXU21AC0
Logic/SSR Relay 1 Yes Yes PXU21B30 PXU21BC0
Logic/SSR Relay 1 Yes Yes PXU21C30 PXU21CC0
Logic/SSR Relay 1 Yes Yes PXU21D30 PXU21DC0
4-20 mA PXU30030
4-20 mA Relay 2 Yes PXU31A30 PXU31AC0
4-20 mA Relay 1 Yes Yes PXU31B30 PXU31BC0
4-20 mA Relay 1 Yes Yes PXU31C30 PXU31CC0
4-20 mA Relay 1 Yes Yes PXU31D30 PXU31DC0
0-10 VDC PXU40030 PXU400C0
0-10 VDC Relay 1 Yes Yes PXU41B30 PXU41BC0
0-10 VDC Relay 1 Yes Yes PXU41C30 PXU41CC0
0-10 VDC Relay 1 Yes Yes PXU41D30 PXU41DC0
1/4 DIN
Relay Relay 2 Yes PXU11A50 PXU11AE0
Logic/SSR Relay 1 Yes Yes PXU21BE0
Logic/SSR Relay 1 Yes Yes PXU21CE0
Logic/SSR Relay 1 Yes Yes PXU21DE0
4-20 mA Relay 2 Yes PXU31A50 PXU31AE0
4-20 mA Relay 1 Yes Yes PXU31BE0
4-20 mA Relay 1 Yes Yes PXU31CE0
4-20 mA Relay 1 Yes Yes PXU31DE0
0-10 VDC Relay 2 Yes PXU41A50 PXU41AE0
0-10 VDC Relay 1 Yes Yes PXU41BE0
0-10 VDC Relay 1 Yes Yes PXU41CE0
0-10 VDC Relay 1 Yes Yes PXU41DE0
Only stocked part numbers are listed. Contact factory for availability of non-stock models.
In order to program the unit using Crimson (Available as a free download from http://www.redlion.net), the unit must be purchased with the RS 485 option.

MODEL NO. DESCRIPTION PART NUMBERS
RLY
External SSR Power Unit (for Logic/SSR models) RLY50000
25 A Single Phase Din Rail Mount Solid State Relay RLY60100
40 A Single Phase Din Rail Mount Solid State Relay RLY6A100
Three Phase Din Rail Mount Solid State Relay RLY70100
PGUSB USB to 485 Converter with Cable PGUSB485
