Select the action for the alarm. See Alarm Action Figures at the
beginning of this section for a visual explanation.
NON
AC2
With normal selection, the alarm annunciator indicates an “on” alarm
output 1. With reverse selection, the alarm annunciator indicates an “off”
alarm output 1.
In Automatic mode, an energized alarm turns off automatically after the
Temperature/Process value leaves the alarm region. In Latched mode, an
energized alarm requires an 1 / 2 key or user input alarm reset to turn
off. After an alarm reset, the alarm remains off until the trigger point is
crossed again.
nor Normal
rv Reverse
Auo Automatic
LA Latched
Select the action for the alarm. See Alarm Action Figures at the
beginning of this section for a visual explanation.
NON
AC1
nor
Li1
Auo
r1
Standby prevents nuisance (typically low level) alarms after a power
up. After powering up the controller, the process must leave the alarm
region (enter normal non-alarm area of operation). After this has
occurred, the standby is disabled and the alarm responds normally until
the next controller power up.
The alarm values are entered as process units or degrees. They may
also be entered in the Parameter or Hidden Loops, when enabled in 3-LC.
When the alarm is configured as deviation or band acting, the associated
output tracks the Setpoint as it is changed. The value entered is the
offset or difference from the Setpoint at which the alarm condition will
occur.
Y Standby on
NO Standby off
-99.9 to 999.9
NO
b1
100.0
AL-1
OFF
IFA1
On OFF
Select the Alarm action in the event of a detected input failure (open
TC/RTD or shorted RTD).
Shaded parameters are programming/model dependent.
NON AbI AbLO AuI AuLO
d-I d-LO b-IN b-o Pr
C1 oLd rPuP rPdn run
PA oP nd
NON AbI AbLO AuI AuLO
d-I d-LO b-IN b-o Pr
C1 oLd rPuP rPdn run
PA oP nd
NON
None
No action, the remaining Alarm parameters
are not available.
AbI
Absolute High
(balanced hysteresis)
The alarm energizes when the Process
Value exceeds the alarm value + 1/2 the
hysteresis value.
AbLO
Absolute Low
(balanced hysteresis)
The alarm energizes when the Process
Value falls below the alarm value -1/2 the
hysteresis value.
AuI
Absolute High
(unbalanced hysteresis)
The alarm energizes when the Process
Value exceeds the alarm value.
AuLO
Absolute Low
(unbalanced hysteresis)
The alarm energizes when the Process
Value falls below the alarm value.
d-I
Deviation High The alarm value tracks the Setpoint value
d-LO
Deviation Low The alarm value tracks the Setpoint value
b-IN
Band Acting (inside) The alarm value tracks the Setpoint value
b-o
Band Acting (outside) The alarm value tracks the Setpoint value
Pr
Profile Error Band Timeout
The alarm energizes when the process
remains outside the error band longer than
the allowable time.
C1
Current Break
The alarm energizes when insufficient
current is detected while the corresponding
control output activated.
oLd
Profile Holding
The alarm energizes when the controller is
in a Hold Phase.
rPuP
Ramping Up to Setpoint
The alarm energizes when the controller is
ramping up to setpoint.
rPdn
Ramping Down to Setpoint
The alarm energizes when the controller is
ramping down to setpoint.
run
Controller Running
The alarm energizes when the controller
profile is running.
PA
Controller Paused
The alarm energizes when the controller
profile is paused.
oP
Controller Stopped
The alarm energizes when the controller
profile is stopped.
nd
Profile Ended
The alarm energizes when the controller
profile is ended.
O.0
AL1L
0.0 to 999.9
Enter the minimum acceptable current level at Ct1
O.0
AL1
0.0 to 999.9
Enter the maximum acceptable current level at C1
The remaining Alarm 1 settings are not available when AC1 = C1
The next two parameter settings are only available when AC1 = C1.
