RED MINI-MAG SIDE SSD MODULE CONTROLS
This section describes the controls for all of the RED MINI-MAG modules.
CONTROL DESCRIPTION
User Key 1 Programmable key
User Key 1 + 2 Press: Eject Media
User Key 2 Programmable key
User Key 1 + 2 Press: Eject Media
REC button Programmable key
Full Press: Record Toggle
Half Press: AF Start
RED MINI-MAG SIDE SSD MODULE CONNECTORS
This section describes the connectors for all of the RED MINI-MAG modules.
Each RED MINI-MAG module mounts to the left side of the EPIC/SCARLET. The rear face of this module features a
slot for inserting a RED MINI-MAG.
WARNING: DO NOT attempt to insert any media type except for the RED MINI-MAG, or any foreign objects, into the
SSD slot, as that may damage the RED MINI-MAG module or camera system.
The EVF/LCD connector on the front face of the RED MINI-MAG module provides digital video, communications, and
power interconnection between the camera system and a RED EVF or RED LCD. Due to the requirement for absolute
data integrity, the pinout of the EVF/LCD connector is not published.
CONNECTOR DESCRIPTION COMPATIBLE PARTS PART NUMBERS
EVF/LCD connector






VIEW/FINDER output


LCD/EVF Cable (Right-to-Right) 7" 790-0158
LCD/EVF Cable (Right-to-Right) 12" 790-0162
LCD/EVF Cable (Right-to-Right) 18" 790-0448
LCD/EVF Cable (Right-to-Right) 32" 790-0449
LCD/EVF Cable (Right-to-Straight) 24" 790-0451
LCD Cable 6' 790-0055
LCD Cable 10' 790-0056
RED MINI-MAG Slot



Slot for inserting a REDMINI-MAG



RED MINI-MAG (120GB) 750-0075
RED MINI-MAG (240GB) 750-0082
RED MINI-MAG (512GB) 750-0078
RED MINI-MAG (1TB) 750-0081
