INSTALL EPIC/SCARLET
MEDIA MODULES
This section explains how to install the following modules to an EPIC or SCARLET
®
camera:
RED MINI-MAG
®
Side SSD Module
Carbon Fiber RED MINI-MAG Side SSD Module
DSMC
®
1.8" SSD Side Module
DSMC 1.8" SSD Side Module (DRAGON)
Carbon Fiber DSMC 1.8" SSD Side Module (DRAGON)
Rear SSD Module
NOTE: These media modules are not compatible with DSMC2
®
cameras.
WARNING: Modules, expanders, and lens mounts are NOT HOT SWAPPABLE, meaning you cannot remove or install
these items while the camera is turned on. Before installing or removing these items, you MUST turn off the camera.
Failure to do so may result in damage to the item or camera that is not covered under warranty.
INSTALL EPIC/SCARLET SIDE MEDIA MODULES
ALUMINUM SIDE SSD MODULE INSTALLATION NOTES
The aluminum side SSD modules attach to the camera using the same screws and tools, so you can easily switch
between these modules. You can attach the aluminum side SSD modules using either of the following screws:
Black M3x0.5 x 6 mm cap screws: These screws come with the standard aluminum EPIC camera and ship with
the DSMC 1.8" SSD Side Module, but can be used with either the aluminum EPIC or SCARLET.
Black M3x0.5 x 5.5 mm cap screws: These screws come with the standard aluminum EPIC SCARLET, but can be
used with either the aluminum EPIC or SCARLET.
CARBON FIBER SIDE SSD MODULE INSTALLATION NOTES
Attach the carbon fiber side SSD modules to the carbon fiber EPIC/SCARLET using only the red (colored) M3x0.5 x 6
mm cap screws that come with the carbon fiber EPIC/SCARLET. The red (colored) screws are made of a different
material than the black screws that come with the standard aluminum camera, and are designed to engage specifically
with the lightweight panels of the carbon fiber EPIC/SCARLET.
WARNING: DO NOT attach a carbon fiber side SSD module using any screws except the red (colored) screws that are
provided. Using other screws, including the screws that come with the standard aluminum camera or side SSD
modules, will strip the through holes and damage the panels of the carbon fiber EPIC/SCARLET.
WARNING: Damage to the camera, carbon fiber side SSD module, or other components of the camera system
caused by using non-approved screws with the carbon fiber side SSD module is not covered under warranty, and may
void the warranty for both the camera and the side SSD module.
