# CONNECTOR DESCRIPTION COMPATIBLE PARTS PART
NUMBERS
N/A REDMAG 1.8" SSD
slot (front)
Slot for inserting a REDMAG 1.8"
SSD
REDMAG 1.8" SSD (48GB) 750-0044
REDMAG 1.8" SSD (64GB) 750-0025
REDMAG 1.8" SSD (128GB) 750-0021
REDMAG 1.8" SSD (256GB) 750-0026
REDMAG 1.8" SSD (512GB) 750-0037
1. Only Silicon Image or HighPoint SATA cards connect to the RED STATION REDMAG 1.8" (Mini) through eSATA.
RED STATION REDMAG 1.8" (MINI)
Figure: RED STATION REDMAG 1.8" (MINI) (Front)
LED COLOR/FLASHING DESCRIPTION
Power Indicator LED Off Powered off and turned off
Red Powered on and turned on
Red flashing (fast) Accessing media
RED STATION REDMAG 2.5"
You can use the RED STATION REDMAG 2.5" to offload content from your REDMAG 1.8" SSD to a third-party
external 2.5" SSD or spinning hard drive. RED does not provide any 2.5" media or drives.
Figure: RED STATION REDMAG 2.5"
