5. FIRST INSTALLATION
The machine should be prepared for use as follows (see Fig. 2):
Make sure that the cable/crane/lift can hoist minimum twice the weight of the machine. (See
Chapter 2: Technical Data for the weight.)
1. Attach a cable to the two hoisting points (1) and one around the rear roller (2).
Keep a safe distance. The machine may start to turn/slide away during hoisting/lifting!
Never crawl under the machine!
2. Carefully lift the machine including the pallet to approx. 100 mm (4”) off the ground.
3. Loosen the pallet (4) by removing the pins (3).
4. Lift the machine and off the pallet.
5. Slowly lower the machine and tilt it until it stands safely on the ground (see Fig. 3).
6. When the machine is off the pallet, remove the top plug of the gearbox and replace it with the
de-aerator included in the delivery.
Use a piece of wood under the machine to protect it.
Fig. 2
