15
4. Set the stabilizer of the lifting arms (2) to 100 mm lateral stroke.
5. Mount the top rod (3) on the tractor and attach it to the machine.
Set the top rod (3) in such a manner that in working position the machine is parallel to the
underground.
If the machine is incorrectly attached to the tractor, the different PTO angles can cause
vibrations in the driveline of the machine. These vibrations may damage the machine.
6. Attach the PTO (4) to the tractor (slip coupling at the machine side) and fold the bracket (5)
into the holder.
Make sure that the 3-point pins are locked using the clips !!
7. Start the tractor and lift the machine.
7.2. Detaching the machine
The machine should be detached in the following manner (see Fig. 5):
1. Drive to a spot where the machine should be detached.
Make sure that the parking place has a firm underground and that the machine cannot
sink.
Make sure that the machine and the tractor cannot move while you are detaching
them !!
Switch off the tractor engine before detaching the machine !!
2. Carefully place the machine on the ground.
Check again whether the machine is stable on the ground.
3. Loosen the top rod (3) and remove it.
4. Disconnect the lifting arms (2) from the machine.
5. Detach the PTO (4) at the tractor side and support it by using the bracket (5).
6. Start the tractor and drive off.
