13
2. Measure the distance ‘B’ of the PTO axle in its shortest position from the locking pin to the
locking bolt.
3. Divide the PTO axle in two parts and remove the protection cap at both ends.
4. The ends of the cylinders and the protection caps should be shortened: (B-A) + 125 mm (4.9”).
5. Smooth off all components and then assemble all components. For this purpose, use lubrication
grease.
6. Mount the PTO axle including the slip coupling at the machine side.
7. Attach the other end of the PTO axle to the tractor.
8. Check the overlap of the cylinders.
Never use the machine if it has a damaged PTO protection cap.
First replace the protection cap.
If the PTO is shortened incorrectly or if another tractor is used, the gearbox may be
overloaded and cause damage.
6.2. Using the PTO axle
The following items must be checked for correct use of the PTO axle:
1. The angle of the rotation points should always be smaller or equal to 30 degrees during work
activities.
2. The PTO axle of the tractor must be parallel to the PTO axle of the machine.
3. The overlap of the cylinders must always be minimum 250 mm (9,8”).
4. Never use the machine if it has a damaged PTO protection cap.
5. See the PTO manual for information about lubrication.
