14.0 TECHNICAL INFORMATION
Generally speaking, the Verti-Drain
®
is not a complicated machine. A few technical items will
be explained. If you still have additional questions, please get in touch with your dealer, who
will be pleased to help you.
2
1
3
4
1
8
9
11
10
7
1
8
4
6
9
5
7
5
6
Fig. 13
14.1 THE CRANKSHAFT
In figure 13, the composition of the PTO is shown. Also see the components page for a
more detailed drawing.
