Redexim Verti-Drain 1513 - 1 Technical Data

9
1.0 TECHNICAL DATA
Model
1513
1517
Working width:
1.32 m (52”)
1.76 m (69”)
Working depth:
Up to 150 mm (6”)
Up to 150 mm (6”)
Tractor speed measured at 540 rpm on PTO:
Pitch 55 mm (2.6”)
Pitch 90 mm (3-1/2”)
Pitch 125 mm (5.1”)
Up to 1.8 km/h (1.1 mph)
Up to 2.9 km/h (1.8 mph)
Up to 4.1 km/h (2.5 mph)
Up to 1.8 km/h (1.1 mph)
Up to 2.9 km/h (1.8 mph)
Up to 4.1 km/h (2.5 mph)
PTO rpm: (max.)
Up to 540 rpm
Up to 540 rpm
Weight:
425 kg (937 lbs)
520 kg (1146 lbs)
Pitch between pins:
55 mm (2-1/8”)
55 mm (2-1/8”)
Pitch in driving
direction:
25 – 125 mm (1” – 7.5”)
25 – 125 mm (1” – 7.5”)
Recommended tractor:
25 HP with minimum lift
capacity of 650 kg
(1450 lbs)
28 HP with minimum lift
capacity of 750 kg
(1653 lbs)
Maximum capacity:
Pitch 55 mm (2.6”)
Pitch 90 mm (3-1/2”)
Pitch 125 mm (5.1”)
Up to 2388 m²/hr (25703
ft²/hr)
Up to 3907 m²/hr (42059
ft²/hr)
Up to 5427 m²/hr (58416
ft²/hr)
Up to 3136 m²/hr (33759
ft²/hr)
Up to 5132 m²/hr (55242
ft²/hr)
Up to 7128 m²/hr (76725
ft²/hr)
Dimensions:
1610 x 970 x 780 mm
(63.4” x 38.2” x 30.7”)
2050 x 970 x 780 mm
(80.7” x 38.2” x 30.7”)
Maximum tine
diameter:
Solid :
12 x 150 mm (1/2”x 6”)
Hollow:
19 x 150 mm (3/4” x 6”)
Solid :
12 x 150 mm (1/2”x 6”)
Hollow:
19 x 150 mm (3/4” x 6”)
Three-point hitch:
3-point CAT 1
3-point CAT 1
Gear casing oil:
80W90 – 0.9 liter
80W90 – 0.9 liter
Lubricant:
EP 2
EP 2
Standard components:
Set solid tines 12 x 150 (1/2”x
6”) with accompanying tine
holders.
Trunk with tools and user
manual.
PTO.
Support legs.
Set solid tines 12 x 150 (1/2”x
6”) with accompanying tine
holders.
Trunk with tools and user
manual.
PTO.
Support legs.
Options:
Hollow tines
Turf hold down fingers
Rear roller
Hollow tines
Turf hold down fingers
Rear roller
