7.6 Flywheel
7.6.1 To disassemble the flywheel
1. Clean around the spark plug.
2. Remove the spark plug cap and the spark plug.
3. Put a piston stop in the spark plug hole.
CAUTION: Make sure that the piston stop
does not go into the exhaust port. There is a
risk of engine damage.
4. Remove the starter unit.
5. Remove the nut that holds the flywheel.
6. Attach the flywheel removal tool to the crankshaft,
refer to
Servicing tools on page 12
. Keep a distance
of approximately 2 mm between the flywheel
removal tool and the flywheel. Hit the flywheel
removal tool lightly with a hammer while you lift the
flywheel with your other hand.
20 - Repair instructions 1108 - 001 - 24.11.2020
