settings, refer to
To adjust the carburetor settings on
page 31
.
Basic factory settings
H = high speed jet 2.0
L = low speed jet 1.75
7.9 Handle and throttle trigger
7.9.1 To disassemble the handle
1. Use a pair of pliers to bend open the cable holder
and remove the throttle wire from the cable holder.
2. Remove the 2 screws, the throttle wire cover and the
throttle wire from the carburetor.
32 - Repair instructions 1108 - 001 - 24.11.2020
