4 Servicing data
4.1 Servicing data
▲ Lubricate with 2-stroke oil.
● Lubricate with grease.
T27
5 - 8 Nm
T27
3 - 4.5 Nm
T27
3 - 4 Nm
T27
2 - 3 Nm
T27
2 - 3 Nm
T27
4 - 5 Nm
T27
5 - 7 Nm
T27
4 - 5 Nm
T27
3 - 4.5 Nm
T27
2 - 3 Nm
6 - Servicing data 1108 - 001 - 24.11.2020
