7.7.5 To examine the spark plug cable
If there is no spark, do the procedure that follows to
examine the connection between the spark plug cable
and the spark plug.
1. Pull the spark plug cable from the spark plug cap.
2. Turn the spring to remove it from the cable.
3. Cut approximately 5 mm of the cable.
4. Put the end of the cable against the stop of the
assembly pliers, refer to
Servicing tools on page 12
.
Then close the pliers to make the new hole.
5. Put the spring into the new hole.
6. Put the cable with the open spring into the other slot
in the pliers. Close the pliers to bend the spring.
CAUTION: Make sure that the spring is bent
90 degrees along the cable.
7. Lubricate the cap with soap and water or equivalent
to make it easier to push it into position.
24 - Repair instructions 1108 - 001 - 24.11.2020
