5. Remove the screws and cable (B). Pull up the
ignition module and spark plug cable.
B
A
6. Replace the ignition module.
7.7.8 To install the ignition module
1. Attach cable (A) to the ignition module. Put the
module in the crankcase. Attach the 2 screws and
cable (B). Do not tighten the screws.
B
A
2. Put in the air gap gauge. Refer to Servicing tools on
page 12 .
1108 - 001 - 24.11.2020 Repair instructions - 27
