7. Use the clutch removal tool to remove the clutch.
The clutch has a left hand thread. Refer to
Servicing
tools on page 12
.
8. Remove the clutch springs.
9. Disassemble the clutch shoes from the hub with a
small screwdriver.
CAUTION: Use rubber brackets in the vise
to prevent damage to the clutch.
10. Remove the 6 screws and remove the gearbox
cover. Use a flat screwdriver if it is necessary.
36 - Repair instructions 1108 - 001 - 24.11.2020
