- 16 -
ALARM OUT Socket
If the socket is set to DC OUT, then, when the radio
receives alerts, the socket will output 6 Volts DC (the
voltage will be less when the radio is only powered with
back-up batteries) to the external device.
(the output polarity is shown underneath the socket)
If the socket is set to SWITCH (as internal POWER
SWITCH), then, when the radio receives alerts, t
turning on
the power of the external device / accessory.
For this function, the socket's electrical maximum
rating is: DC voltage: 12 Volt.
DC current: 350mA.
connected
he
internal power switch will be 'closed' and to
connected
Press STOP key to 'open' the internal switch.
Refer to program menu page P8 (SIREN TEST) to test
this function, if necessary.
The ALARM OUT socket is provided on the back of the
radio. The socket's output is compatible with home
automation devices from suppliers such as Plug'n Power,
X-10 or others. Connect a 3.5mm (1/8inch) phone jack
with polarity as indicated underneath the socket.
AUDIO OUT Socket
1. Press and hold PROG key for 2 seconds to enter program
menu page. Skip this step if it is now in program menu.
2. Keep pressing key to menu page P7.
3. Press ENTER key to select.
4. Press key to select DC OUT or SWITCH option.
5. Press ENTER key to confirm.
To exit the program menu, press PROG key.
The socket outputs siren and voice broadcast signal to
the external audio systems such as Public Address
system, external speaker system and etc.
When it is necessary to use this socket, connect the
3.5mm (1/8 inch) phone jack to the socket with polarity
as indicated underneath the socket; the speaker voice is
muted. The volume keys or , controls the audio
output level.
