Specification:
Power Supply: 9 - 14 Volt DC
Back-up Battery: 6 Volt (4 'AA' batteries)
The fresh alkaline battery will power the radio up to 40
hours in standby mode.
Operating Temperature: 0 C (32 F) ~ +50 C (122 F)
Weather Band Receiver:
Receiving sensitivity @12 dB SINAD: 0.22uV
FIPS code sensitivity
@ +/- 4.0KHz Dev.: 0.24uV
Channel Selectivity: 60dB
S/NRatio: 45dB
Distortion: 3%
Max output power: 250mW
Dimensions (HWD): 203mm x 138mm x 47mm
(8 x 5.4 x 1.85 inches)
AM/FM Band Receiver:
FM Band: 87.5MHz - 108.5MHz
AM Band: 520KHz - 1710KHz
Channel:
Freq.(MHz) 162.4 162.425 162.45 162.475 162.5 162.525 162.55
1 2 3 4 5 6 7
Specifications are typical; individual units might vary.
Specifications and features are subject to change and
improvement without prior notice.
