Reflex Variomat User Manual

Controller
16 — English Master/Slave Operation — 24.09.2015
12. Press "Number of Slaves".
Settings>Service>Master/Slave
(240) Address 1
(241) Master/Slave No
(242) Number of Slaves 0
(243) Max. pressure deviation 1 bar
2.9 bar 0 %
13. Specify the number of slaves.
– In the master, specify the number of slaves.
– You can specify a maximum of 10 slaves.
– Do not enter a number in the slaves (Number = 0).
– Use the buttons to enter the number.
– Press "OK" to confirm.
Settings>Service>Master/Slave
(242) Number of Slaves
4
2.9 bar 0 %
14. Press "Max. pressure deviation".
Settings>Service>Master/Slave
(240) Address 1
(241) Master/Slave No
(242) Number of Slaves 4
(243) Max. pressure deviation 1 bar
2.9 bar 0 %
OK

Reflex Variomat Specifications

General

Membrane material	EPDM
Maximum operating pressure	10 bar
Application	Heating and solar systems
Fluid	Water, glycol mixtures
Operating pressure	10 bar
Control	Automatic
Material	Steel
