Reflex Variomat User Manual

Controller
18 — English Master/Slave Operation — 24.09.2015
18. Press "Max. level deviation".
Settings>Service>Master/Slave
(244) Activation delay 5s
(245) Max. level deviation 5%
(246) Block message 29 PFK? No
2.9 bar 0 %
19. Specify the value for the maximum level deviation for the
device tanks.
– This parameter is meaningless in the master and can be
ignored.
– Define the parameter in the slaves.
– Setting range 0–20 %.
– Use the buttons to enter the parameter value.
– Press "OK" to confirm.
Settings>Service>Master/Slave
(245) Max. level deviation
_5%
2.9 bar 0 %
20. Press "Block message 29 PFK".
Settings>Service>Master/Slave
(244) Activation delay 5s
(245) Max. level deviation 5%
(246) Block message 29 PFK? No
2.9 bar 0 %
OK

Reflex Variomat Specifications

General

Membrane material	EPDM
Maximum operating pressure	10 bar
Application	Heating and solar systems
Fluid	Water, glycol mixtures
Operating pressure	10 bar
Control	Automatic
Material	Steel
