28 | P36-10 Zero Clearance Direct Vent Gas Fireplace
|
28
installation
The shaded area in the diagrams show the
allowable vertical terminations.
8' Min.
40-1/2”
30' Max.
30
Horizontal Distance (Feet)
Vertical Height (feet)
2’ max.
VENTING ARRANGEMENTS - VERTICAL TERMINATION
with Co-linear Flex System for both
Residential & Manufactured Homes into Masonry Fireplaces
