42 | P36-10 Zero Clearance Direct Vent Gas Fireplace
|
42
installation
WALL THERMOSTAT
(OPTIONAL)
A wall thermostat may be installed if desired,
connect the wires as per the wiring diagram.
Use the table below to determine the maximum
wire length.
Note: Preferable if the thermostat is
installed on an interior wall.
Regencyoffers an optional programmable
thermostat but any 250-750 millivolt rated non-
anticipator type thermostat that is CSA, ULC or
UL approved may be used.
CAUTION
Do not connect millivolt
wall thermostat wires
to 120V wire.
Recommended Maximum Lead Length
(Two-Wire) When Using Wall
Thermostat (CP-2 System)
Wire Size Max. Length
14 GA. 50 Ft.
16 GA. 32 Ft.
18 GA. 20 Ft.
20 GA. 12 Ft.
22 GA. 9 Ft.
Thermostat Wire Table
Install the supplied battery into the DC Sparker Box
by opening the battery compartment.
NOTE: The battery in the DC Sparker Box will
need to be replaced annually.
DC SPARK IGNITER
BATTERY INSTALLATION
