Corrigo E Heating manual, revision G Chapter 1 14
Empty wiring diagram Corrigo E15H
1 G 50 B
2 G0
Supply voltage 24 V AC, ±15%. 50/60 Hz
51 A
3 Protective earth 52 N
4 +C +24 V DC. Reference for digital inputs DI. 53 E
RS485 EXOline / Modbus
10 G Reference for digital outputs DO. 57 Net+
11 DO1 58 Net-
12 DO2 59 Egnd
LON-connection (LON-versions only)
13 DO3
14 DO4 71 DI1
72 DI2
30 Agnd Reference pole for analogue inputs 73 DI3
31 AI1 74 DI4
32 AI2
33 Agnd Reference pole for analogue inputs 90 Agnd Reference for analogue outputs AO
34 AI3 91 AO1
35 AI4 92 AO2
93 AO3
Empty wiring diagram Corrigo E8H
1 G 50 B
2 G0
Supply voltage 24 V AC, ±15%. 50/60 Hz
51 A
3 Protective earth 52 N
4 +C +24 V DC. Reference for digital inputs DI. 53 E
RS485 EXOline / Modbus
10 G Reference for digital outputs DO. 57 Net+
11 DO1 58 Net-
12 DO2 59 Egnd
LON-connection (LON-versions only)
30 Agnd Reference pole for analogue inputs 71 DI1
31 AI1 72 DI2
32 AI2 73 DI3
90 Agnd Reference for analogue outputs AO
91 AO1
