Corrigo E Heating manual, revision G Chapter 12 Manual / Auto 45
Chapter 12 Manual / Auto
General
In this menu the running mode of the unit and all the configured outputs can be manually controlled.
This is a very handy feature which simplifies the checking of individual functions in the Corrigo.
It is also possible to manually control each of the temperature output signals individually.
All the configured digital outputs can be set to On, Off or Auto.
Since leaving any of the outputs in manual control will disrupt the normal control, an alarm will be
generated as soon as any output is set to a manual mode.
Since the menus vary according to the configuration of the outputs only the most common ones will
be shown here. For the digital signals you can normally choose between Auto and On and Off or
similar words indicating the two possible manual states of the digital output.
Heating systems HS1, HS2 and HS3
Manual/Auto
HS1
Auto
Manual set: 0.0
Hot water circuits HWC1 and HWC2
Manual/Auto
HWC1
Auto
Manual set: 0.0
Pressure control
Pressure control
Auto
Manual set: o.o
Minmum set: 0.0
Pumps HS1, HS2 and HS3
Manual/Auto HS1
P1A:Auto
P1B: Auto
Pump HWC1
Manual/Auto
HWC1:Auto
Frequency converter start
Manual/Auto
Frequency conv.:Auto
