Corrigo E Heating manual, revision G Chapter 8 Configuration 27
8.1.2 Digital inputs DI
Digital input 1
NO/NC: NO Signal:
HS1-PumpA
Status: Off
To simplify adaptation to external functions, all digital inputs can be configured to be either
normally open, NO, or normally closed, NC.
The inputs are as standard normally open, i. e. if the input is closed, the function connected to the
input in Corrigo is activated.
8.1.3 Universal inputs UI
On the largest hardware version, E28 there are universal inputs. These can individually be
configured as either analogue inputs or as digital inputs. When configured as analogue inputs they
can be bound to any of the analogue signals described under Analogue signals.
When configured as digital inputs they can be bound to any of the digital signals described under
Digital signals.
Universal input 1 Æ
Choose AI or DI sign
AI sign: HS2 Supply
DI sign: Not active
After choosing AI or DI signal (the unused alternative must be set to Not active) there is a sub-menu
with settings used when the input is configured as an AI-input. This menu is accessed by pressing
RIGHT.
Universal AI1
Sign: HS2 Supply
Raw value:38.5
Compensation: 0.0°C
Input signals can be compensated for example for wiring resistance.
The Raw value will show the actual uncompensated input value.
If an input has been assigned to pressure control the following submenu will be available:
UAI1 Pressure at
0V: 0.0 kPa
10V: 10.0 kPa
Filter factor: 0.2
Universal DI1
NO/NC: NO Signal:
HS1-PumpA
Status: Off
To simplify adaptation to external functions, all universal inputs configured as digital inputs can be
set as either normally open, NO, or normally closed, NC.
The inputs are as standard normally open, i. e. if the input is closed, the function connected to the
input in Corrigo is activated.
8.1.4 Analogue outputs
Analogue outputs are 0…10 V DC.
Analogue output 1
Sign: HS1 Actuator
Auto
Value: 2.3 V
