Corrigo E Heating manual, revision G Chapter 8 Configuration 26
Chapter 8 Configuration
Start by logging on at System level. See section Access rights above.
Using DOWN, set the display marker opposite the menu-title Configuration and press RIGHT.
The main configuration menu will be shown.
Inputs/Outputs
HS Supply
Return temp
Pump stop
Twin/Single pump
Run ind/Motor prot
Actuator type
Actuator run time
Actuator exercise
Leakage monitoring
Pulse inputs
Alarm config.
Other params
System
8.1 In- and Outputs
Analogue inputs
Digital inputs
Universal inputs
Analogue outputs
Digital outputs
General
Free configuration
Any control signal can be bound to any input/output, the only restriction being that digital signals
cannot be bound to analogue inputs and vice versa. It is up to the user doing the binding to make
sure that activated functions are bound to appropriate signals.
Delivery setting
On delivery all the physical inputs and outputs have already been bound to a signal.
The delivery settings are suggestions only and can easily be changed.
8.1.1 Analogue inputs AI
Analogue input 1
Sign: Outdoortemp
Raw value: 18.3
Compensation: 0.0°C
All analogue inputs are for PT1000 or 0-10 Volts.
Input signals can be compensated for example for wiring resistance.
The Raw value will show the actual uncompensated input value. If an input has been assigned to
pressure control the following submenu will be available:
AI2 Pressure at
0V: 0.0 kPa
10V: 10.0 kPa
Filter factor: 0.2
To Next Page
