Corrigo E Heating manual, revision G Chapter 8 Configuration 28
8.1.5 Digital outputs
Digital output 1
Signal: HS1-PumpA
Auto
Status: On
8.2 HS Heating System, supply
8.2.1 Parallel displacement
To each of the set control curves can be added a parallel displacement.
Parallel displacemnt
HS1: 0.0 °C
HS2: 0.0 °C
HS3: 0.0 °C
8.2.2 Maximum limit
A maximum supply temperature can be set individually for each heating system.
Maximum limit
HS1: 98 °C
HS2: 98 °C
HS3: 98 °C
8.2.3 Minimum limit
A minimum supply temperature can be set individually for each heating system.
Minimum limit
HS1: 0 °C
HS2: 0 °C
HS3: 0 °C
8.2.4 Auto-correction of setpoint
Room sensors can be used to correct the control curves. The average room temperature error over
24 hours is calculated. Values 1 hour before and 1 hour after a day/night or night/day change-over
are ignored. The curves are corrected once daily using the average room temperature error and a
settable correction factor. The correction will be a parallel displacement of the entire curve using the
following formula:
Displacement = (Room setpoint - Average temp)*Factor
Auto-correction
Setpoint HS1
On Æ
Corr. factor HS1
2.0
Present correction
0.6°C
