Corrigo E Heating manual, revision G Chapter 8 Configuration 29
8.3 Return water temperature
Individual maximum and minimum return water temperatures can be set for the heating systems.
Should the water temperature go outside the set limits the supply water temperature will be adjusted
to correct. The adjustment will be the temperature offset multiplied by the set limiting factor.
8.3.1 Maximum temperature
Max. return temp.
HS1:Active Æ
HS2:Inactive
HS3:Inactive
Max. return temp
HS1: 50°C
HS2: 50°C
HS3: 50°C
8.3.2 Minimum temperature
Min. return temp.
HS1:Active Æ
HS2:Inactive
HS3:Inactive
Min. return temp
HS1: 0°C
HS2: 0°C
HS3: 0°C
8.3.3 Limiting factor
Return limit factor.
HS1: 1.00
HS2: 1.00
HS3: 1.00
8.4 Pump stop
Each heating system has individual day and night stop temperatures. An active circulation pump
will stop if the outdoor temperature is higher than the set value and there is no heating demand. The
pump will start if the temperature falls below the set stop temperature less the set hysteresis. Night
is between 00:00 am and 05:00 am.
All pumps, even resting twin-pumps, are exercised once daily for 5 minutes at 3 pm.
Pump stop HS1:On
Temp stop day: 17°C
Temp stop night 17°C
Hysteresis: 2.0°C
