Corrigo E Heating manual, revision G Chapter 8 Configuration 36
Type 4
The second line shows the outdoor temperature.
The third line shows the text HS1.
The fourth line shows the present temperature setpoint and actual values for HS1.
Heating Regulator
Outdoor temp: 8.2°C
HS1
Sp:32.8°C Act:33.1°C
8.14.3 Automatic summer time adjustment
The internal clock is normally configured for automatic summertime/wintertime adjustment. The
function can be disabled in this menu. When enabled, the clock will be advanced one hour at 02:00
am the last Sunday of March and retarded one hour at 03:00 am the last Sunday of October.
Automatic summer/
winter time change
over
Yes
8.14.4 Address
Corrigo E uses the addresses below when connecting to Corrigo E-tool, and when multiple
controllers are connected in a network. E-tool normally uses the addresses below, so if an address is
changed, the new address must also be entered in E-tool. If several Corrigo are connected in a
network, all the units must have the same ELA address, but each unit must have a unique PLA
address.
Address
PLA: 254
ELA: 254
8.14.5 Display anywhere (Remote control)
If multiple Corrigo units are connected in a network, it is possible to remote control a unit in the
network from a unit with display. You do this by entering the address of the unit you wish to remote
control in the unit with display. The function is aborted by pressing the buttons UP, OK and DOWN
simultaneously.
Address for
remote communication
(PLA:ELA) 00:00
8.14.6 Communication code Modbus
If Corrigo is to be wired to a network for Modbus communication, a special code must be purchased
from Regin. Entering the code unlocks the unit so the addresses can be changed.
The code is unique for each Corrigo and is serial-number dependent.
Communication code
for modbus
0
Modbus: Not Active
Modbus Address: 1
Speed: 9600 bps
Two stop bits:Yes
Parity:No
