24
Manual CORRIGO U-SERIE 2002-09
Alarm settings
Here all settings for the alarm system are set including alarm parameters, delays,
suppression times etc.
1. Temperature deviation alarm HS1
Should the actual temperature differ from the setpoint by more than the set
value an alarm will be activated after a set time.
2. Temperature deviation alarm HS2 (CORRIGO U20 only)
Should the actual temperature differ from the setpoint by more than the set
value an alarm will be activated after a set time.
3. Temperature deviation alarm HW
Should the actual temperature differ from the setpoint by more than the set
value an alarm will be activated after a set time. Only active if HW has been
configured.
4. Temperature deviation alarm THW
Should the actual temperature differ from the setpoint by more than the set
value an alarm will be activated after a set time. Only active if THW has been
configured.
5. Alarm HWC-P
0. No
1. Yes
6. Alarm output suppression
The alarm output relay can be blocked so that unprioritised alarms will only be
forwarded during the set time and not during the night or weekends, for
example. Outside the set period only frost alarm, high temperature alarm and
fire alarm will activate the alarm relay.
Set the times in this menu when alarms are forwarded to the alarm relay
output.
Example: An alarm is only to activate the alarm output between 08.00 and
17.00, Monday to Friday. The setting will be as follows:
N.B. Even if the alarm output is blocked the alarm will be registered and
indicated by the red flashing alarm diode and the alarm list menus will function
as normal.
Alarm out 08:00
MTWTF___ -17:00
Temp.dev. alarm
5.0K / 2 min
