27
Manual CORRIGO U-SERIE 2002-09
Commissioning protocol U10
Configuration Factory setting Commissioning setting
Config. code 1 1100.1100.0000 ____._____._____
Config. code 2 0000.0110.11 ____._____.___
A. AI1 1 Outdoor temp _______________
B. AI2 1 HS1 Supply _______________
C. AI3 0 -------- _______________
D. AI4 0 -------- _______________
E. AI5 1 HW Supply _______________
F. AI6 1 THW Supply _______________
G. Not available for U10 0 ---- Code must be 0
H. Not available for U10 0 ---- Code must be 0
I. HS1 Night setback 0 No _______________
J. HS1 Room compensation 0 No _______________
K. HS1-CV1 Type 0 0...10 V DC _______________
L. Not available for U10 0 ---- Code must be 0
M. Not available for U10 0 ---- Code must be 0
N. Not available for U10 0 ---- Code must be 0
O. Not available for U10 0 ---- Code must be 0
P. Not available for U10 0 ---- Code must be 0
Q. Control THW 0 1 sequence _______________
R. Control HW 1 Yes _______________
S. Control HS1-P 1 Yes _______________
T. Not available for U10 0 ---- Code must be 0
U. Indication HWC 1 Yes _______________
V. Daylight saving 1 Yes _______________
Control HS1
Man. offset 0 _______________
Setpoint room 20.0°C _______________
Nightreduction / Standby -1.0 / -2.0 _______ / ______
Outdoor plot 1 -20.0°C / 65.0°C _______ / ______
Outdoor plot 2 -10.0°C / 55.0°C _______ / ______
Outdoor plot 3 -5.0°C / 50.0°C _______ / ______
Outdoor plot 4 ±0.0°C / 43.0°C _______ / ______
Outdoor plot 5 +5.0°C / 35.0°C _______ / ______
Outdoor plot 6 +10.0°C / 30.0°C _______ / ______
Outdoor plot 7 +20.0°C / 20.0°C _______ / ______
PBand / I-time 60K / 120 s _______ / ______
Runtime HS1-CV1 180 s _______________
Control HW / THW
HW Setpoint 60°C _______________
HW P / I / D 60°C / 60 s / 0.0 _____/_____/____
THW Setpoint 55°C _______________
THW P / I / D 60°C / 60 s / 0.0 _____/_____/____
Installation
System
Commiss.date Commiss. by
