Manual CORRIGO U-SERIE 2002-09
Commissioning protocol U20
Configuration Factory setting Commissioning setting
Config. code 1 1100.1110.0000 ____._____._____
Config. code 2 0000.0111.11 ____._____.___
A. AI1 1 Outdoor temp _______________
B. AI2 1 HS1 Supply _______________
C. AI3 0 -------- _______________
D. AI4 0 -------- _______________
E. AI5 1 HW Supply _______________
F. AI6 1 THW Supply _______________
G. AI7 1 HS2 Supply _______________
H. AI8 0 ---- _______________
I. HS1 Night setback 0 No _______________
J. HS1 Room compensation 0 No _______________
K. HS1-CV1 Type 0 0...10 V DC _______________
L. HS1-CV2 0 No _______________
M. HS2 Night setback 0 No _______________
N. HS2 Room compensation 0 No _______________
O. HS2-CV1 Type 0 0...10 V DC _______________
P. VS2-SV2 0 Nej _______________
Q. Control THW 0 1 sequence _______________
R. Control HW 1 Yes _______________
S. Control HS1-P 1 Yes _______________
T. Control HS2-P 1 Yes _______________
U. Indication HWC 1 Yes ________________
V. Daylight saving 1 Yes ________________
Control HS1
Man. offset 0 _______________
Setpoint room 20.0°C _______________
Nightreduction / Standby -1.0 / -2.0 _______ / ______
Outdoor plot 1 -20.0°C / 65.0°C _______ / ______
Outdoor plot 2 -10.0°C / 55.0°C _______ / ______
Outdoor plot 3 -5.0°C / 50.0°C _______ / ______
Outdoor plot 4 ±0.0°C / 43.0°C _______ / ______
Outdoor plot 5 +5.0°C / 35.0°C _______ / ______
Outdoor plot 6 +10.0°C / 30.0°C _______ / ______
Outdoor plot 7 +20.0°C / 20.0°C _______ / ______
PBand / I-time 60K / 120 s _____/_____/____
Runtime HS1-CV1 180 s ________________
Installation
System
Commiss.date Commiss. by
Page 1
