Alarm events
Alarm log, containing the 40 latest alarm events. The
most recent event is listed first. The alarm log can only
be used for viewing the alarm history. Alarms are
handled in a special area, see the section Alarm
handling.
Inputs/Outputs
These menus show the current values for all configured
inputs and outputs.
These are read-only menus. No changes can be made
here.
Universal inputs can be configured as either analogue or digital inputs.
Analogue inputs and digital outputs are shown here as examples.
Analogue inputs/outputs
The current values for the analogue inputs and outputs
are shown here.
Digital inputs/outputs
This menu shows if the digital inputs and outputs are On
or Off.
24 Nov 14:32 B
Malfunction supply
air fan
Acknowledged
AI
DI
UI
AO
DO
AI1: 18.5 Outd temp
AI2: 20.3 Supply temp
AI3: 28.2 Frost prot
AI4: 19.9 Room temp1
DO1:Off SAF 1/1-speed
DO2:Off EAF 1/1-speed
DO3: On SAF 1/2-speed
DO4:Off EAF 1/2-speed

Regin Corrigo Specifications

General

Category	Controller
Manufacturer	Regin
Power Supply	24 V AC/DC
Type	Programmable controller
Protection Class	IP20
Mounting	DIN rail
Output Voltage	24 V AC/DC
Communication Protocols	Modbus, BACnet
Inputs	Analog, Digital
Outputs	Analog, Digital
Model	Corrigo
