Regin Corrigo User Manual

Fel! Använd fliken Start om du vill tillämpa heading 1 för texten som ska visas här. Corrigo ventilation user
guide, revision F
16
During recirculation, offset SAF makes it possible to add to the supply air fan an offset to
the setpoint during normal operation.
If pressure control has been configured, the offset is set in Pa. If flow control has been
configured, it is set in m3/h. If manual control has been configured, the offset is set in %.
If you have selected the Offset function, which is a deviation from the regular supply air
setpoint, you will instead be given the option to change this offset value here.
Extra controller unit
An independent temperature control circuit for control of for
example after-heaters. The circuit can be configured to either
heating or cooling.
Enthalpy control
Enthalpy control is a function for overriding the mixing damper
output signal to recirculation if the enthalpy is higher outdoors
than indoors.
Submenu for reading of outdoor temperature and
outdoor air humidity.
Submenu for reading of indoor temperature and air
humidity in the room.
Shows if enthalpy control is active or not.
Extra unit
Actual: 21.2°C
Setpoint: 20.0°C
Enthalpy indoor:
35.5 kJ/kg
Enthalpy outdoor:
36.4 kJ/kg
Outd temp
Act: 19.2 °C
Humidity outdoors
Act: 51.1 % RH
Indoor temp
Act: 19.9°C
Humidity indoors
Act: 44.3 % RH
Override cool
recovery due to
enthalpy:
Active
