Example: At the lower end the setpoint is increasing by 1°C for every 5 °C lowering of the
outdoor temperature. So the setpoint at –23°C would be 25°C + 0.6x 1.0°C = 25.6°C.
Setpoint Cascaded room temperature control
In control mode Supply air control/Room control, the
setpoint is used when cascade connected room control is
active.
Submenu for setting the min and max limitation
temperatures for the supply air.
If two room sensors have been configured you
will also get this menu. The controller uses the
average temperature of the two sensors.
Setpoint Cascaded extract air temperature control
In control mode Supply air control/Extract air control,
the setpoint is used when cascaded extract air control is
active.
Sub menu for setting the min and max limitation
temperatures for the supply air.
Setpoint Outdoor compensated room temperature/extract air control
Offers the possibility to compensate the room
temperature/extract air temperature against the outdoor
temperature. Note that the curve must be adjusted for optimal
functionality!
Room temp1
Actual: 22.0°C
Setpoint: 21.5°C

If cascade control
max/min supply setp
Max: 30.0°C
Min: 12.0°C
Room temp2
Actual: 21.8°C
Extract air temp
Actual: 21.0°C
Setpoint: 21.1°C
If cascade control
max/min supply setp
Max: 30.0°C
Min: 12.0°C
Room temp1
Actual: 22.0°C
Setp: 21.5°C

