2.2.7 Required Components for Zone Control
Masters/ Add On modules
Quantity
Components REHAU Art. No. Heating Heating/Cooling
REHAU BA 202236-001 No Yes
BA Cooling Kit 202233-001 No Yes
Add On, Module 225115-002 Up to 8 zones: 0x
Up to 14 zones: 1x
Wired Sensors/Controllers
Components REHAU Art. No. Constant Flow Temperature
REHAU CT2 (Programmable Room Sensor) 225108-002 Minimum:1x (same time setting in all zones)
Maximum:14x (different time setting in all zones)
REHAU TP (Tamper resistant sensor) 225109-001 Up to 8 zones: maximum of 7x
Up to 14 zones: maximum of 13x
REHAU TA (Standard Sensor) 225106-001
REHAU TD (Comfort plus sensor, includes floor sensor) 225116-001
REHAU TM (Comfort sensor) 225107-002
REHAU HS (Humidity sensor) 229435-001 No
Actuators 241293-002 Minimum:1x per controlled circuit
Maximum:12x per manifold / controller
Switch fused spur Not supplied 1x
Net Extension kit 202239-001 If the distance between the master and the Add On Module exceeds 0.3m, then net extension kit
is required. This includes 2 connector blocks each with 2 small cables with RJ45 connectors
Wireless Sensors/Controllers
Components REHAU Art. No. Constant Flow Temperature
REHAU RF CT2-RH 202246-001 Minimum:1x (same time setting in all zones)
Maximum:14x (different time setting in all zones)
REHAU RF TP 202253-001 Up to 8 zones: maximum of 7x
Up to 14 zones: maximum of 13x
REHAU RF TA 202251-001
REHAU RF TD 202245-001
REHAU RF TM 202254-001
REHAU RC 202244-001 Minimum: 1x
Maximum: 5x
Communication distance: Up to 30m inside building and 100m line of sight
